Double sheet ravioli machine Toresani Pavan model RR230

The model RR/230 is engineered in order to produce ravioli and agnolotti with two overlapped sheets, cut into dozens or separated, in different shapes and sizes: square, half-moon or round and triangular, in a variable weight from 2,5 up to 35 grams each, and with a meat or cheese and vegetables filling.

Two calibrating groups with adjustable opening and with cylinders on self-lubricant bushes are calibrating the dough sheet and conveying same through the forming group.

This forming group is composed by: 1) a roll with cavities to lead the filling; 2) a counter roll for sealing the two sheets; 3) a cutter roll

The cutter roll, being adjustable, allows a more or less deep impression up to separate each raviolo from the strip.

The filling feed is continuous. A stainless steel conical screw, rotating at a variable speed, doses the filling in a pre-chamber. A semi-rotating valve separates - in the right moment - the screw from the pre-chamber.

A close-valve piston pushes the filling dose into the conveyor.

A set of distributors bring each filling dose to the mould.

Both valve and piston are driven by cams, allowing more time to dose and therefore a continuous and slow rotating of the screw, in order to keep inalterated the filling consistence.

The screw speed variation is obtained by D.C. motor with panel registration.

For a more constant production - from the smaller up to the bigger shapes - both the speed of the two calibrators, the sheet and the forming group are constant.

A single interchangeable gear modifies the distributors strokes number accordingly with the number of ravioli contained along the forming roll circumference.

Both the forming roll and the distributors block are interchangeable and therefore the ravioli machine can be supplied with more moulds as below listed.

The machine is provided with safety devices.

This machine comes with a mm. 45 square shape new mould with round filling pocket (10 grams each); the machine produces up to 283 Kgs. / hour of double sheet ravioli, separated one by one, depending on the selected mold. Other interchangeable moulds are available, see available shapes at https://www.raviolishapes.com.

Electrical equipment 220 / 400 V - 3 phases - 50 / 60 Hz., completely rebuilt, guaranteed 1 year, CE and USDA approved.
